Laser Cutting Machines

Model Name/Number 1390/1313/1410 Laser Type Sealed-off Glass CO2 Laser Wavelength: 10.6um Brand w2lt Laser Power 100W/130W/150W Cutting Speed 600mm/s Working Area 1300x1300mm Voltage AC220V/110V+-10% Frequency 50HZ/60HZ Engraving Speed 1200mm/s Working Humidity 95% Laser Output Control 0-100% No section control, Soft inner 0-100% adjustable. Reposition Accuracy less than or equal to +/- 0.01mm Operating Temperature 45 Degree C Rise and Fall Height 100mm (adjusted manually) Optional Part Motorized up and down table and rotary device Laser Tube Cooling Water cooling Control System and Driver High Speed DSP control system or RD Controller and stepper motor, High subdivision driver Machine Power less than or equal to 1000W Minimum Letter Size Chinese : 1.5mm English :1mm Features Professional design for client in different industry, reasonable structure, pleased appearance & practical. High strength & high stable mechanical structure composed of high precision mould , machine moved stable, in high speed & precision , back-open design convenient for material process & no limit for material length Adopt flight path design, special structure, little path deviation, high performance & easy adjustment. Update USB offline control system & large memory capacity to improve work speed & efficiency Up and down table and Rotary device is optional.
