Vikram MonoPerc Solar Panel(Half cut)

Maximum Power Output 440-530 W Type Mono PERC Power Output Upto 500 W Brand Vikram Number of cells 144 cells MNRE Approved Yes Module Efficiency 20.46% Weight 25.3 Kg Max Power current 10.93 Max Power Voltage 41.6 Country of Origin Made in India Vikram Solar panel Feature : EFFECTIVE GAIN OF 1% OF CELL ACTIVE AREA by using cylindrical tabbing wire Bypass diodes and innovative series-parallel connections enable the module to perform better in PARTIAL SHADOW CONDITIONS BETTER TOLERANCE TO MICRO CRACK Higher number of busbar makes the PV modules less prone to loss in efficiency due to micro-cracks. IMPROVED FIELD RELIABILITY due to multiple contact points on the cell. SUPERIOR PRICE PERFORMANCE half-cut improves the output of the module without adding much to cost Spec: Length : 2118mm Width : 1050mm Height : 40mm Weight : 25.3 Kg Cells : 72 Mono PERC (144 half-cells) Fuse Rating : 20 A
