Flux Meter
Measuring Range 0- 200000 Lux
Brand STAR TRACE
Resolution 1 Lux
Accuracy 10 %
Country of Origin Made in India
INTRODUCTION :Star Trace Pvt. Ltd. is a renowned manufacturer and supplier of unbeatable quality Magnetic Field Flux Meters.
Digital Flux Meter Model-STFM 110 :Introduction :
Model STFM-110 Electronic Flux Meter measures magnetic flux cut.
Specifications :
Measuring Range : 10³, 104 and 106 Kilomaxwell turns with 100% over range protection.
Indication : 3 1/2digit panel meter with 12 mm LED.
Resolution : 1 Kilomaxwell Turns range.
Accuracy : ±0.5% of full Scale.
Input Resistance : 10 Kilo Ohms.
Drift : Less then 0.5% of full scale per minute on 10’Kilomaxwell turns range.
Output Voltage : 1 Kilomaxwell turns range.
Input Power : 240 V, 50 Hz, 25 VA.
Output Resistance : 1 Kilo Ohms.
Dimensions : 210 x 95 x 225mm, Weight 1 Kg.
Optional : Recorder output of 1V across 1 Kilo Ohms.
Applications :
Used in Measuring D.C. Magnetic fields, Ferro Magnetic Detectors, Field Surveyors, Production Test Systems, Voltage Integration, Hysteresis Loop Tracers and Magnetic Shielding Tester.
Digital Flux Meter Model-STFM 201 :
Model STFM 201fluxmeter is an advanced version of Model STFM 110. It is a high speed precision instrument which integrates with any voltages signal when applied to its input terminals.
