S And T Machinery Private Limited
We are one of the foremost manufacturer of CNC Vertical Machining Center, Cylindrical Grinding Machine & Double Column Machining Centers and much more. Our professionals work in close coordination to assure a high-quality assortment of products to the customers. We have recruited a team of professionals. In addition to this, to avoid disputes in the workplace, our professionals strive dedicatedly. Owing to our fare policies and the best quality products.
Under the direction of our mentor, Mr. Doraiswamy Shanmugasundaram, we are creating a long list of clients. Also, owing to his knowledge, commitment, skills, and ethical business strategies, we have been able to achieve a renowned position in the market.
Preview
22,1Singanallur,,Coimbatore,
Coimbatore - 641005
Coimbatore - 641005
Contact Details
STM CNC Double Column Machining Center DL 2619
Product Details:
Usage/Application Industrial
Machine Type Fully Automatic
Brand STM
Automation Grade Automatic
Model Name/Number DL 2619
Headstock balancing system Two cylinder
ATC Type Arm type
X/Y/Z Axis 2600/1900/900 mm
Machine net weight 21000 Kg
Spindle taper BT50
Table Length / Width 2500 /1500 mm
Table Load 7000 kg
CNC controller Mitsubishi
X / Y / Z axis motor power 7 / 7 / 7
T-Slot(Width * number * pitch) 22X160X9 mm
Main Structure HT300
Country of Origin Made in India
A’ shaped structured column with multiple cross ribs offers high cutting performance.
Wide base offers very higher stability for big size jobs during heavy duty machining.
LM Roller Guideways for all 3 axes provides higher cutting dynamics and longer machine life.
Imported spindles from Taiwan with G1 balanced grade offers superior finish up to 0.45Ra Value.
Controller options with latest configuration from Mitsubishi and Fanuc available.
High efficiency and productivity can be ensured with Fred rate of 10,000mm/min and rapid feed rate of 36 m/min.
Coimbatore - Tamil Nadu
