Rakesh.G., Global Exports
“Global Exports” is the well-known entity established in the year 2010 at Kochi, Kerala (India). The company is prominent Manufacturer and Exporter of superior quality Boring Machines, Grinding Machine, Hydraulic Honing Machine and much more. Automatia is client manufacturing brand.
We believe in maximizing the highest level of contentment of our customers by providing them with an entirely streamlined range of Industry Machines. The expert technocrats in our team work with strong determination and dedication to achieve the pre-determined goals of our firm.
Preview
No. 34 / 313- A, Chiramel, Near Government L. P. S.,Padivattom, Edappally Post Office,,
Cochin - 682024
Cochin - 682024
Contact Details
Automatia ASG 1800 Vertical Surface Grinding Machine
Brand Automatia
Maximum Milling Width 420 mm
Grinding Wheel Motor Power 3 hp,980 rpm 3 Ph,415 V,50Hz
Grinding Head Spindle Speeds 250,550,1000 rpm
Servo Motor Table Traverse 750 W
Shipping Volume 15.2 m3 (Approx)
Table Clamping Surface 1800 x 400 mm
Grinding Head Rapid Movement Variable (MPG) (Servo with Ball Screw)
Servo Motor Grinding Head Movement 400 W
Gross Weight 3500 kg (Approx)
Model No ASG - 1800
Table Feed Rate Variable (Servo With Ball Screw)
Automatic Table Travel 1800 mm
Max Distance Between Table Wheel Head 1000 mm
Packing Case Dimensions 3500 x 1600 x 2800mm (LxWxH)
Distance From Column to Table Center 400 mm
Coolant Motor Power 0.25 h.p
Maximum Grinding Width 400 mm
Maximum Grinding Length 1600 mm
Segment Wheel Dia 400 mm
Hand Feed for Grinding Head MPG 1 div/0.01 mm
Table Movement Precision Ball Screw
Vertical Head Traverse 1050 mm
Cochin - Kerala
