Electric Chain Hoists

Brand CarlStahl Control Voltage 48V Phase 3 Phase Lift Speed 8m/2mm to 4m/1mm Motor Power 1.5/0.37Kw to 2.4/0.6 Kw Weight 125 kgs to 2000 kgs Frequency 50Hz Voltage 380-415V Hook Center Distance 1000-4000mm Hoist Rating IP55 Lift Height 3-12m Chain Size 7x20 to 9x27 inch Capacity Range 2X500KG TO 2X1600KG Duty Cycle Dual Speed-40/200% ED Class Of Duty 2m/M5 Operating Temperature -100 Degree C to +50 Degree C Fall 1 to 2 CT Speed 25/6m/min Pendant Rating IP65 Available Model Ca 2010T And CA 3216T Description- Single speed and dual speeds are available. hoist can be at a fixed position, move with hand operated push pull or gear type and mostorised trolley as available. Electromagnetic DC fail-safe brake positively arrestes the load when the hoist is stopped or in the event of power failure, All gears are alloy steel, high precision cut, mounted on antifrication ball bearing and in oil bath. Over load friction clutch acts as emergency limit stop for the highest and lowest hook position and protects against overloads. Standard hoist 3 meter lift and equipped with suitable chain collector, control panel and pendent station. higher lift will be provided at an extra cost. Befortless and Balanced Lifting:-Twin hook electric chain hoists are equipped with two hooks with a single operating motor and gear box. most suitable for lifting applications requiring two lifting points for a wide load or retaining a lebvel lifyting and in a synchronous way. twin hook chain hoists are simple, reliable and smooth running. Sprocket:- Two chains are winded up to the same sprocket. Rotary limits switch:- Over travel limit is controlled by geared limit switch as standard. Hook Center:- Each hoist is built with a specific hook centers that best fits the given application. Optimal Space Utilization:- Compact dimensions and best hook approach. Applications:- Motor Brake Transmission Slipping Clutch Chain Wheel Chain Unique Chain Guide Forged Carbon Steel Hooks Rotary Limit Switch Frame Assembly
