Vertical Milling Machine
To cater the variegated demands of our clients, we are highly engrossed in providing a wide range of Vertical Milling Machine.
Features:
Smooth operations
Long service life
Minimum maintenance
Technical Specifications of All Geared Universal Milling Machines:
PARTICULARS PMI 2 PMI 3 PMI 4 PMI 5
TABLE
Working Table overall size 1300mm x 275mm 1400mm x 325mm 1600mm a 350mm 1800mm x 500mm
T-slots No./Width/Center Distance 3/13mm/65mm 3/15mm/75mm 3/15mm/80mm 5/20mm/100mm
Swivel of Table 45° 45° 45° 45°
SPINDLE
Arbor Diameter 25. 25. 25. 32
No. 8 Range of Speeds 9(50-950) 9(50-950) 9(50-950) 12(40-1250)
Taper of Spindle (50-40 ISO-40 150-40 ISO-50
FEEDS
X-Longitudinal 650 700 800 1050
Y-Cross 200 280 330 400
Z-Vertical 405 535 610 625
NO. & RANGE OF FEEDS (Per min.) 18 18 18 18
