End Milling Machine- It350 A
Model Name/Number END MILLING MACHINE- IT350 A
Brand ITALIAN
Machine Type END MILLING MACHINE
Material Aluminium
Automation Grade Automatic
Power Source 440 V / 3 PH
Weight 180 KGS
Machine Height 1300
Dimension Mm L110*W800*H1300
Horizontal end milling with manual feeding, milling at 45/90/-45 and intermediate degrees with quick change of the cutter block.
Equipped with spindle at 2800rpm with usueful stoke 390mm. Max cutter diameter 200mm.
Threephase motor 2.5 HP. Working pressure 7 bar.
Overall dimensons 104x72x130 cm.
Widht 140 kg. 180 Kg.
Motor: HP 2.5, V.220/380 2800 giri Blade Emm. 200 max. I mm. n/12800
Dimensions Max Profile 250 a 90 ,80 a 45Operating pressure 6/7 Atm. Pneumatic clamps.
STANDARD EQUIPMENT -
Pneumatic claming set - Turret stop for presetting 6 milling deps - Pneumatic lubrication lubrication Nr. 1 cutter block 32mm - Air gun - Air filter - Full protection guard - Service spanners.
OPTIONALS -
Single phase motor - Cutter block 32mm - Emulsified cutting oil 20 lt
